export@fluiremax.com - GST NO. : 09AZEPR8376F1ZS
| Business Type | Manufacturer, Exporter, Trader |
| Brand Name | FLUIREMAX |
| Type | Check Valve |
| End Connection | Flanged, Wafer, Screwed, Butt Weld |
| Click to view more | |
Product Details
Usage
Industrial Applications Such As Water Treatment, Oil/gas, Marine, Petrochemical
Certification
ANSI, API, DIN, JIS, IBR, CE, And ISO Approved
Size
1/2 To 24 Inch
Pressure Rating
150 To 1500 PSI
Material Available
CF8, CF8M, WCB, AISI 304, AISI 316
Industries Served
Water Treatment, Oil & Gas, Petrochemical, Food & Beverage, Power Plants, Marine & Chemical Industries
Key Features & Benefits
- Quality & Innovation: Our valves are manufactured using high-grade materials with rigorous quality checks ensuring long service life and impeccable performance.
- Tailored Solutions: FLUIREMAX valves meet industry-specific requirements for water treatment, oil/gas, marine, petrochemical, and more.
- Standard Compliance: All products are API, ANSI, DIN, and ISO approved to offer safe and reliable operation across various industrial applications.
- (Visual: Infographic summarizing these benefits, integrating our brand colors and logo.)
- Application & Industry Certifications
Certifications:
- ANSI, API, DIN, JIS, IBR, CE, and ISO Approved
- Industries Served:
- Water Treatment
- Oil & Gas
- Petrochemical
- Food & Beverage
- Power Plants
- Marine & Chemical Industries
Check Valves
- Type: Swing / Dual Plate / Lift Check
- Size: 1/2” to 24”
- Pressure Rating: 150# to 1500#
- Material: CF8, CF8M, WCB, AISI 304, AISI 316
- End Connection: Flanged, Wafer, Screwed, Butt Weld
Check Valve specifications and Price list
| Check Valve specifications and Price list | ||||||||||
| Size | MOC | Body Material | Trim Material | Seat Material | Pressure Class | End Connection | Additional Info | MOC | Weight | Price in USD |
| DN 15 | CF8 | ASTM A 351M Gr CF8 | AISI 304 | AISI 304 | 150# | Flanged [RF] | – | CF8M | 3.5 | 140 |
| DN 15 | WCB | ASTM A 216 Gr WCB | AISI 410 | AISI 410 | 150# | Flanged [RF] | – | CF8 | 3.5 | 116 |
| DN 15 | CF8M | ASTM A 351 Gr CF8M | AISI 316 | AISI 316 | 150# | Flanged [RF] | – | WCB | 3.5 | 71 |
| DN 25 | CF8 | ASTM A 351 Gr CF8 | AISI 304 | AISI 304 | 150# | Flanged [RF] | – | CF8 | 6.5 | 204 |
| DN 25 | WCB | ASTM A 216 Gr WCB | AISI 410 | AISI 410 | 150# | Flanged [RF] | Serrated finish; Valve Code: NLALCS2 | WCB | 6.5 | 110 |
| DN 25 | CF8 | ASTM A 304 / CF8 | AISI 304 | AISI 304 | 150# | Flanged [RF] | “Flanged as per ASME B16.5 / Class 150” | WCB | 6.5 | 83 |
| DN 25 | WCB | ASTM A 216 M WCB | AISI 410 | AISI 410 | 150# | Flanged [RF] | “Flanged as per ASME B16.5 / Class 150” | CF8 | 6.5 | 161 |
| DN 40 | CF8 | ASTM A 351 Gr CF8 | AISI 304 | AISI 304 | 150# | Flanged [RF] | – | WCB | 12 | 188 |
| DN 40 | CF8M | ASTM A 351 Gr CF8M | AISI 316 | AISI 316 | 150# | Flanged [RF] | – | CF8 | 12 | 292 |
| DN 40 | CF8 | ASTM A 304 / CF8 | AISI 304 | AISI 304 | 150# | Flanged [RF] | “Flanged as per ASME B16.5 / Class 150” | CF8M | 12 | 375 |
Looking for "Heavy Duty Industrial Check Valve" ?
Piece
